Description
SPECIFICATIONS
User Memory
Patterns: 128 (16 patterns x 8 banks)
Tracks: 8
Steps
32 steps
Sequencer Functions
STEP LOOP
SUBSTEP
FLAM
INTRO / FILL IN
PROBABILITY
SUBSTEP PROBABILITY
MASTER PROBABILITY
Instruments
BD: BASS DRUM*
SD: SNARE DRUM*
LT: LOW TOM*
HT: HI TOM*
CY: CYMBAL*
OH: OPEN HI HAT
CH: CLOSED HI HAT
* Variation sounds included
Controllers
VOLUME knob
RUN/STOP button
PATTERN CLEAR button
MENU/SUB STEP button
STEP LOOP button
FUNCTION button
TEMPO button
STEP buttons (1-16)
PATTERN GROUP button and indicators
TAP/STEP RESET button
SCALE selector switch
INSTRUMENT selector knob
MODE selector knob
VALUE knob
Instrument Level knobs (AC, BD, SD, LT/HT, CY, OH/CH)
Effect knobs (DRIVE, TIME, DEPTH)
Effects
Compressor
Delay Effects: DELAY, PAN DELAY, TAPE-ECHO, REVERB, FLANGER, SIDE BAND FILTER
Drive Effects: SATURATOR, BIT CRUSHER, DISTORTION, LPF/HPF
Indicators
7 segments, 4 characters (LED)
Connectors
TRIGGER IN jack: mono miniature phone type
TRIGGER OUT jack x 5 (AC, BD, SD, LT, HT): mono miniature phone type
PHONES jack: stereo miniature phone type
OUTPUT jack: stereo miniature phone type
MIX IN jack: stereo miniature phone type
MIDI (IN, OUT) connectors
USB port: Micro-B type (Audio, MIDI)
Power Supply
Rechargeable Ni-MH battery (AA, HR6) x 4
Alkaline battery (AA, LR6) x 4
USB bus power
Current Draw
500 mA (USB bus power)
Expected battery life under continuous use
Rechargeable Ni-MH battery: Approx. 5 hours
* This can vary depending on the specifications of the batteries, capacity of the batteries, and the conditions of use.
Accessories
Boutique Dock: DK-01 (Silver)
Owner's Manual
DK-01 Owner's Manual
Leaflet "USING THE UNIT SAFELY"
Alkaline battery (AA, LR6) x 4
