Description
SPECS
neck type PS3pc OkoumeSet-in neck (smooth heel)
top/back/body Maple topOkoume body
fretboard Bound Ebony fretboardAcrylic & Abalone block inlay
fret Medium frets
number of frets 22
bridge Gibraltar Performer bridge
string space 10.5mm
tailpiece Quik Change III tailpiece
neck pickup Seymour Duncan® '59 model™ (H) neck pickupPassive/Alnico
bridge pickup Seymour Duncan® Custom 5™ (H) bridge pickupPassive/Alnico
factory tuning 1E,2B,3G,4D,5A,6E
strings D'Addario® EXL110
string gauge .010/.013/.017/.026/.036/.046
nut Bone nut
hardware color Chrome
NECK DIMENSIONS
Scale : 628mm/24.7"
a : Width 43mm at NUT
b : Width 57mm at 22F
c : Thickness 20mm at 1F
d : Thickness 23.5mm at 12F
Radius : 305mmR
