Description
SPEC
SPECS
neck type EHB45pc Roasted Maple/Walnut neck w/Graphite reinforcement rods
top/back/body American Basswood body
fretboard Roasted Birdseye Maple fretboardAbalone off-set dot inlay
fret Medium Stainless Steel frets
number of frets 24
bridge MR5HS bridge
string space 19mm
neck pickup Bartolini® BH2 neck pickupPassive
bridge pickup Bartolini® BH2 bridge pickupPassive
equaliser Vari-mid 3-band EQ w/ EQ bypass switch (passive tone control on treble pot)
factory tuning 1G,2D,3A,4E
strings D'Addario® EXL165
string gauge .045/.065/.085/.105
hardware color Black
NECK DIMENSIONS
Scale : 762mm/30"
a : Width 41mm at NUT
b : Width 64mm at 24F
c : Thickness 19.5mm at 1F
d : Thickness 21.5mm at 12F
Radius : 500mmR
