Description
Headplate Pau Ferro
Electronics Vendor & Model Fishman OEM-PSY-B11
Neck Joint Dovetail
Headstock Logo Cordoba Arches Logo - Mother-of-Pearl
Back Purfling Inlay Pattern & Dimensions N / A
Back Binding Pau Ferro
Back Center Strip Pau Ferro
Nut String Spacing 40mm
Side Purfling Inlay Pattern & Dimensions N / A
Tuning Machines Vendor & Model Der Jung DJ206CK-P12 (S3)
Tail Strip Pau Ferro
Tuning Machine Ratio 14:1
Tuning Machine Buttons Black
Pickup Type Undersaddle Piezo, Onboard Tuner
Frets to Body 12
Middle Pickup None
Battery Pack Inside Preamp Compartment - 9V
Battery Pack Installation Location Flip Up Preamp
Waist Width 235mm (9 1/4")
Number of Strings 6
Exclusive to N / A
Does it contain shell? Yes - MOP
Shipper Carton Dimensions 104 x 47 x 14 (cm)/ 41 x 18.5 x 5.5 (inches) - Cordoba Guitar Triangle Box (No Case)
Master Carton Dimensions 111.5x58x69 (cm) / 43.9x22.8x16x27.2 (inches) - Cordoba Triangle Master Carton (6 Pack)
Tuning E-A-D-G-B-E
pcid 1
psid 4
Item Number 05413
Family Cutaway & Electric
Build Fusion
Construction Solid Top
Body Top Solid Western Red Cedar
Top Bracing Pattern Fan
Soundhole Diameter 84mm (3 1/3")
Rosette Maple and Black Rings
Top Purfling Inlay 6-ply Maple and Black
Top Binding Pau Ferro
Side Purfling Inlay N / A
Back and Sides Wood Mahogany
Neck Material Mahogany
Scale Length 650mm (25.6")
Neck Shape Crossover C Shape
Nut Width 48mm (1 7/8")
Neck Thickness 1st Fret 21mm
Neck Thickness 9th Fret 24mm
Truss Rod Dual Action
Truss Rod Wrench 4mm Allen Key
Fingerboard Material Pau Ferro
Fingerboard Inlays N / A
Frets Total 19
Color Natural (NAT)
Finish Gloss Polyurethane
Bridge Material Pau Ferro
Saddle Material Bone
Nut Material Bone
Tuning Machines Cordoba Silver with Black Buttons
Tap Plate N / A
Electronics Fishman Presys
Strings Savarez Alliance /Cantiga High Tension 510AJ
Included Case Case Sold Separately
Upper Bout Width 279mm (11")
Lower Bout Width 368mm (14 1/2")
Body Depth Upper Bout 85mm (3 1/3")
Body Depth Lower Bout 95mm (3 3/4")
Body Length 483mm (19")
Overall Length 978mm (38 1/2")
Country of Origin China
