Description
Tuning Machine Ratio 14:1
psid 1
Back Purfling Inlay Pattern & Dimensions N / A
Neck Construction Traditional 3 Piece Neck
Neck Joint Dovetail
Frets to Body 12
Number of Strings 6
Waist Width 248mm (9 3/4")
Headplate Composite
Back Center Strip Composite
Headstock Logo Cordoba Arches Logo - Maple
Battery Pack Installation Location Lower Bout Treble Side
Battery Pack Fishman Combination Battery Box/Output Jack - 9V
Middle Pickup None
Pickup Type Undersaddle Piezo, Onboard Tuner
Electronics Vendor & Model Fishman PSY-BAF-AAA
Tuning Machine Buttons Pearl White
Tuning Machines Vendor & Model Der Jung DJ216GK-A1W (S2)
Back Binding Composite
Side Purfling Inlay Pattern & Dimensions N / A
Soundboard Thickness 2.8 - 3.0 mm
pcid 1
Tail Strip Composite
Tuning E-A-D-G-B-E
Top Purfling Pattern & Dimensions N / A
Shipper Carton Dimensions 104 x 47 x 14
Does it contain shell? No
Exclusive to N / A
Item Number 04662
Family Cutaway & Electric
Build Thinbody
Construction Solid Top
Body Top Solid Spruce
Top Bracing Pattern Fan
Soundhole Diameter 84mm (3 1/3")
Rosette All Wood Traditional
Top Binding Composite
Side Purfling Inlay N / A
Back and Sides Wood Spalted Maple
Back Purfling Inlay N / A
Neck Material Mahogany
Scale Length 650mm (25.6")
Neck Shape C Shape
Nut Width 50mm (2")
Neck Thickness 1st Fret 21mm
Neck Thickness 9th Fret 24mm
Truss Rod Dual Action
Truss Rod Wrench 4mm Allen Key
Fingerboard Material Pau Ferro
Fingerboard Inlays N / A
Frets Total 19
Color Natural (NAT)
Finish Gloss Polyurethane
Bridge Material Pau Ferro
Saddle Material Bone
Nut Material Bone
Tuning Machines Cordoba Gold with Pearl Buttons
Tap Plate N / A
Electronics Fishman Presys II
Controls Tuner, Volume, Bass, Treble, and Phase Switch
Strings Savarez Cristal Corum High Tension 500CJ
Included Case Case Sold Separately
Upper Bout Width 292mm (11 1/2")
Lower Bout Width 371mm (14 5/8")
Body Depth Upper Bout 65mm (2 1/2")
Body Depth Lower Bout 70mm (2 3/4")
Body Length 489mm (19 1/4")
Overall Length 984mm (38 3/4")
Country of Origin China
